TR5902 | Dominator Air Spring Replaces 58343
Description : Dominator Air Spring Replaces 58343
Part Number : TR5902
Dominator 2500 lbs Air Spring
| Brand | Reference Numbers |
|---|---|
| Air Lift | 58343 |
| Property | Value |
|---|---|
| Maximum Extended Height | 10.5" |
| Compressed Height | 2.8" |
| Maximum Load at 100 PSI | 2,030 lbs |
| Maximum Diameter | 7" |
| Design Height | 5.5" ‑ 7.5" |
| Air Fitting Size | ½" |
| Bottom Fastener | 3/8 16 |
| Top Fastener | 3/8 16 |
| Mounting Hole Center | 1.75" Top/Center/Bottom |
