TR7215 | Cabin Air Spring for Freightliner Trucks
Description : Cabin Air Spring for Freightliner Replaces 18-52651-000, 1S5-175
Part Number : TR7215
Cabin Air Spring for Freightliner Trucks
| Brand | Reference Numbers |
|---|---|
| Automann | ABSZ70‑7215 |
| Sampa | 500.867‑01 |
| Alliance | ABP N32 027215 |
| Contitech | 68161, SC31Y215, SC31‑Y215 |
| Firestone | 7111, 7215, W023587207, W02‑358‑7207, W023587215, W02‑358‑7215, W023777215, W02‑377‑7215 |
| Freightliner | 1840977000, 18‑40977‑000, 1852651000, 18‑52651‑000, 1852651001, 18‑52651‑001, 1866715000, 18‑66715‑000 |
| Goodyear | 1S5175, 1S5‑175 |
| Triangle | AS‑5215 |
| Property | Value |
|---|---|
| Locating Pin Height | 0.61" |
| Air Inlet | Push‑to‑connect air fitting |
| Design Height | 9.44" |
| Piston Diameter | 2.91" |
| Minimum Jounce Height | 5.78" |
| Extended Height | 12.40" |
| Compressed Height | 5.78" |
| Weight | 1.39 lbs |
