TR25593 | Actuator Surelok Air Spring
Description : Actuator Surelok Air Spring Replaces S-25593, S-24488, 5593
Part Number : TR25593
Actuator Surelok Air Spring for Hendrickson Suspensions
| Brand | Reference Numbers |
|---|---|
| Automann | ABSZ70‑5593 |
| Sampa | 501.151‑01 |
| Contitech | 77550 , SC26‑WC12 |
| Firestone | 5593 |
| Goodyear | 57908017200000 |
| Hendrickson | C24488, C‑24488, C25593, C‑25593, S24488, S‑24488, S25593, S‑25593 |
| Property | Value |
|---|---|
| Locating Pin Diameter | 1/2" |
| Locating Pin Height | 1/2" |
| Air Inlet | 1/8" NPT |
| Design Height | 7.09" |
| Piston Diameter | 2.66" |
| Extended Height | 14.00" |
| Compressed Height | 4.00" |
| Weight | 2lbs |
