TR83048 | Heavy Duty Shock Absorber for Volvo VN, VNM, and VNL Trucks
Description : Heavy Duty Shock Absorber for Volvo VN, VNM, and VNL Trucks
Part Number : TR83048
Heavy Duty Shock Absorber for Volvo VN, VNM, and VNL Trucks
| Brand | Reference Numbers |
|---|---|
| Gabriel | 83048 |
| Monroe | 66107, 66109, 66199 |
| Volvo | 20704334, 20721254, 21368413, 21391412, 22662125, 22662224, 22662235, 22866844, 83176194, SA3048, 20496215, RCSA3048 |
| Volvo/White | 20496215 |
| Automann: | A83048 |
| Sampa: | 502.818 |
| Property | Value |
|---|---|
| Extended length | 9.97" |
| Collapsed length | 8.43" |
| Stroke | 2.37" |
| Dust tube | Yes |
| Recoil Cutoff | Yes |
| Upper Mounting | I.D. 0.55" sleeve length 2.44" |
| Lower Mounting | I.D. 0.55" sleeve length 2.31" |
| Rebound force | 904 |
| Compression force | 415 |
| Bore | 1‑3/8" |
| Weight | 3.5lbs |
