TR7001 | Cabin Air Spring for Kenworth and Mack Trucks
Description : Cabin Air Spring for Kenworth and Mack Replaces T81-1001, 227QS33
Part Number : TR7001
Cabin Air Spring for Kenworth and Mack Trucks
| Brand | Reference Numbers |
|---|---|
| Automann | ABSZ70‑7001 |
| Sampa | 500.900‑01 |
| Contitech | 67770, SC29‑O001, SZ70‑5067 |
| Firestone | 7001, W023587001, W02‑358‑7001, W023587002, W02‑358‑7002, W023587031, W02‑358‑7031 |
| IHC | 2501293C1 |
| Kenworth | R811001, R81‑1001 |
| Mack | 227QS33 |
| SZ | 705067 |
| Triangle | AS‑5001 |
| RoadLeveler | AS70010, RL70010 |
| Link | 11010023, 1101A023, 11020020, 11020023, 1102A023, 1102K023 |
| Property | Value |
|---|---|
| Locating Pin Diameter | 3/8"‑16 |
| Locating Pin Height | 0.50" deep |
| Air Inlet | 1/8" NPT |
| Design Height | 8.5‑10.2" |
| Piston Diameter | 2.9" |
| Extended Height | 8.38" |
| Compressed Height | 2.30" |
| Weight | 1.8 lbs |
