TR83125 | Heavy Duty Shock Absorber for Trailers and Mack Trucks
Description : Heavy Duty Shock Absorber for Trailers and Mack Replaces 83125
Part Number : TR83125
Heavy Duty Shock Absorber for Trailers and Mack Trucks
| Brand | Reference Numbers |
|---|---|
| Automann: | 565.ER3043 |
| Sampa: | 503.108 |
| Gabriel: | 83125 |
| Ford: | F4HT18045EA, F5HZ18124D, F5HZ18124DA |
| Hendrickson: | 47902025, 4790225 |
| Holland: | 6898, 90045535 |
| Mack: | 14QK410M, 14QK410M3, 25625234, 25625254, 4790225 |
| Meritor: | 83125 |
| Neway: | 90044680, 90044687 |
| Tectran: | 11604 |
| Trailmobile: | 90044625 |
| Volvo: | 1091347 |
| Volvo/White: | 1091347 |
| Property | Value |
|---|---|
| Extended length | 28.15" |
| Collapsed length | 17.16" |
| Stroke | 10.99" |
| Dust tube | Yes |
| Recoil Cutoff | Yes |
| Rebound force | 625 |
| Compression force | 115 |
| Upper Mounting | I.D. 0.75",<wbr> sleeve length 1.75" |
| Lower Mounting | I.D. 0.75",<wbr> sleeve length 1.75" |
| Bore | 1‑3/8" |
| Weight | 6.5 lbs |
